基于频域波束降维的车载雷达多参数联合超分辨方法

doi:10.12305/j.issn.1001-506X.2024.10.10

系统工程与电子技术 ›› 2024, Vol. 46 ›› Issue (10): 3325-3333.doi: 10.12305/j.issn.1001-506X.2024.10.10

• 传感器与信号处理 • 上一篇

基于频域波束降维的车载雷达多参数联合超分辨方法

刘润虎¹^,², 曹丙霞¹^,*, 李迎春¹, 闫锋刚¹, 金铭¹

1. 哈尔滨工业大学(威海)信息工程研究所, 山东威海 264209
2. 哈尔滨工业大学电子与信息工程学院, 黑龙江哈尔滨 150001

收稿日期:2023-06-16 出版日期:2024-09-25 发布日期:2024-10-22
通讯作者: 曹丙霞
作者简介:刘润虎 (1998—), 男, 博士研究生, 主要研究方向为阵列信号处理、毫米波雷达信号处理
曹丙霞 (1988—), 女, 副教授, 博士, 主要研究方向为阵列信号处理、雷达电子对抗
李迎春 (1987—), 男, 副教授, 博士, 主要研究方向为雷达系统、多源融合感知技术
闫锋刚 (1982—), 男, 教授, 博士, 主要研究方向为自适应信号处理、电子对抗
金铭 (1968—), 男, 教授, 博士, 主要研究方向为阵列信号处理、雷达系统设计
基金资助:
国家自然科学基金(61971158);国家自然科学基金(62171150);国家自然科学基金(62001143);泰山学者工程专项经费(TSQN202211087);山东省自然科学基金(ZR2023MF091)

Frequency-domain beam dimension reduction based multi-parameter joint super-resolution algorithm for vehicle radar

Runhu LIU¹^,², Bingxia CAO¹^,*, Yingchun LI¹, Fenggang YAN¹, Ming JIN¹

1. Institute of Information Engineering, Harbin Institute of Technology (Weihai), Weihai 264209, China
2. School of Electronics and Information Engineering, Harbin Institute of Technology, Harbin 150001, China

Received:2023-06-16 Online:2024-09-25 Published:2024-10-22
Contact: Bingxia CAO

摘要/Abstract

摘要：

针对车载雷达多参数联合超分辨计算复杂度高、无法快速实现参数估计的问题, 提出了基于频域波束降维的多参数联合超分辨算法。所提算法通过快速傅里叶变换(fast Fourier transform, FFT)将空时多参数域联合数据变换到频域, 处理感兴趣区域的多维频域数据, 完成空时波束空间降维和基于频域数据的多参数联合超分辨, 实现目标信息的快速联合估计。推导了频域子空间正交性及频域波束降维超分辨算法理论。仿真研究了算法的分辨率和估计性能与信噪比的关系。仿真结果表明, 所提算法的精度和分辨率远超传统FFT算法, 相对于传统多重信号分类(multiple signal classification, MUSIC)算法, 所提算法计算量大幅降低。

关键词: 频域, 波束空间, 联合超分辨, 多重信号分类

Abstract:

Aiming at the problem that the multi-parameter joint super-resolution of vehicle radar has high computational complexity and cannot achieve parameter estimation quickly, a multi-parameter joint super-resolution algorithm based on frequency-domain beam dimension reduction is proposed. The proposed algorithm transforms the joint data of space-time multi-parameter domain to frequency domain by fast Fourier transform (FFT), to process multi-dimensional frequency-domain data of the region of interest and complete the dimension reduction of the beam-space in space-time and the multi-parameter joint super-resolution based on the frequency-domain data, which achieve fast joint estimation of target information. The theory of frequency-domain subspace orthogonality and frequency-domain beam dimension reduction super-resolution is deduced. The relationship between the resolution, estimation performance of the algorithm and the signal to noise ratio (SNR) is investigated in simulation, and the simulation results show that compared with the traditional FFT, the accuracy and resolution of the proposed algorithm have been greatly improved, and the computational quantity is greatly reduced compared with that of the multiple signal classification (MUSIC) algorithm.

Key words: frequency domain, beam-space, joint super-resolution, multiple signal classification (MUSIC)

中图分类号:

刘润虎, 曹丙霞, 李迎春, 闫锋刚, 金铭. 基于频域波束降维的车载雷达多参数联合超分辨方法[J]. 系统工程与电子技术, 2024, 46(10): 3325-3333.

Runhu LIU, Bingxia CAO, Yingchun LI, Fenggang YAN, Ming JIN. Frequency-domain beam dimension reduction based multi-parameter joint super-resolution algorithm for vehicle radar[J]. Systems Engineering and Electronics, 2024, 46(10): 3325-3333.

图/表 10

图1

图2

表1

表2

表3

图3

图4

图5

图6

表4

参考文献 30

1	HEO J M , JUNG Y C , LEE S J , et al. FPGA implementation of an efficient FFT processor for FMCW radar signal processing[J]. Sensors, 2021, 21 (19): 6443. doi: 10.3390/s21196443
2	WU J C, CUI H, DAHNOUN N. An improved angle estimation algorithm for millimeter wave radar[C]//Proc. of the 11th Mediterranean Conference on Embedded Computing, 2022.
3	LI S B, ZHAI Y, YANG B, et al. Smoothing method for range and angle super resolution frequency-division-multiplexing FMCW MIMO radar[C]//Proc. of the IEEE 6th International Conference on Signal and Image Processing, 2021: 590-594.
4	SCHMIDT R . Multiple emitter location and signal parameter estimation[J]. IEEE Trans.on Antennas and Propagation, 1986, 34 (3): 276- 280. doi: 10.1109/TAP.1986.1143830
5	CHEN L , YE C B , LI B B . Computationally efficient ambiguity-free two-dimensional DOA estimation method for coprime planar array: RD-root-MUSIC algorithm[J]. Mathematical Problems in Engineering, 2020, 2020 (23): 2794387.
6	YAN F G , MENG X T , GRECO M S , et al. Half-dimension subspace decomposition for fast direction finding with arbitrary linear arrays[J]. IEEE Signal Processing Letters, 2022, 29, 1482- 1486. doi: 10.1109/LSP.2022.3185952
7	MENG X T , CAO B X , YAN F G , et al. Real-valued MUSIC for efficient direction of arrival estimation with arbitrary arrays: mirror suppression and resolution improvement[J]. Signal Processing, 2023, 202, 108766. doi: 10.1016/j.sigpro.2022.108766
8	ROY R , KAILATH T . ESPRIT-estimation of signal parameters via rotational invariance techniques[J]. IEEE Trans.on Acoustics, Speech, and Signal Processing, 1989, 37 (7): 984- 995. doi: 10.1109/29.32276
9	ESFANDIARI M, VOROBYOV S A. Enhanced standard esprit for overcoming imperfections in DOA estimation[C]//Proc. of the IEEE International Conference on Acoustics, Speech and Signal Processing, 2021: 4375-4379.
10	QI J, ZHANG Y, XIE G Z, et al. Joint range, elevation, and azimuth estimation for 77 GHz FMCW radar with a rectangular array[C]//Proc. of the IEEE 10th Asia-Pacific Conference on Antennas and Propagation, 2022.
11	ZHAN C H , HU G P , ZHAO F Z , et al. Co-prime MIMO radar for DOD, DOA, and Doppler frequency estimation with low complexity[J]. IEEE Access, 2023, 11, 66568- 66578. doi: 10.1109/ACCESS.2023.3291342
12	SUN F G, OUYANG S Q, LAN P, et al. Reduced dimensional 2D DOA estimation via least partial search with automatic pairing for parallel co-prime arrays[C]//Proc. of the IEEE 11th Sensor Array and Multichannel Signal Processing Workshop, 2020.
13	CAO Z, LIU Y X, CAI Z R. Low computation complexity methods for DOA estimation[C]//Proc. of the Global Reliability and Prognostics and Health Management, 2022.
14	LIU X, LIU Z Y, ZHAO Y W, et al. Low complexity DOA estimation algorithms based on propagator for massive MIMO systems[C]//Proc. of the IEEE 22nd International Conference on Communication Technology, 2022: 121-126.
15	BIENVENU G, KOPP L. Decreasing high resolution method sensitivity by conventional beamformer preprocessing[C]//Proc. of the IEEE International Conference on Acoustics, Speech, and Signal Processing, 1984: 714-717.
16	VAN-TREES H L . Optimum array processing: Part Ⅳ of detection, estimation, and modulation theory[M]. New York: Library of Congress Press, 2002.
17	VAN-TREES H L. 最优阵列处理技术[M]. 汤俊, 译. 北京: 清华大学出版社, 2008.
	VAN-TREES H L. Optimal array processing technology[M]. TANG J, Trans. Beijing: Tsinghua University Press, 2008.
18	KOH C L, WEISS S, LIU W. A comparison of adaptive beamforming implementations for wideband scenarios[C]//Proc. of the 2nd IEE/EURASIP Conference on DSPenabledRadio, 2005: 11086.
19	GODARA L C . Application of the fast Fourier transform to broadband beamforming[J]. The Journal of the Acoustical Society of America, 1995, 98 (1): 230- 240. doi: 10.1121/1.413765
20	ZHENG Q W , YANG L J , XIE Y P , et al. A target detection scheme with decreased complexity and enhanced performance for range-Doppler FMCW radar[J]. IEEE Trans.on Instrumentation and Measurement, 2020, 70, 8001113.
21	ZHU L U , LIU Y S , HE D P , et al. A low-complexity noise reduction algorithm for enhanced target detection in FMCW radar[J]. IEEE Trans.on Vehicular Technology, 2023, 72 (12): 15227- 15236. doi: 10.1109/TVT.2023.3289817
22	XU S Q, CHEN B X, CHEN X Y, et al. A beamspace dimension reduction technique with application to DOA estimation in low-angle tracking[C]//Proc. of the CIE International Conference on Radar, 2021: 1585-1588.
23	LI X R , WANG X D , YANG Q , et al. Signal processing for TDM MIMO FMCW millimeter-wave radar sensors[J]. IEEE Access, 2021, 9, 167959- 167971. doi: 10.1109/ACCESS.2021.3137387
24	杨希博. TDM-MIMO高分辨雷达阵列优化及DOA算法研究[D]. 成都: 电子科技大学, 2021.
	YANG X B. TDM-MIMO optimization high resolution radar array and DOA algorithm research[D]. Chengdu: University of Electronic Science and Technology of China, 2021.
25	BARAL A B , TORLAK M . Joint Doppler frequency and direction of arrival estimation for TDM MIMO automotive radars[J]. IEEE Journal of Selected Topics in Signal Processing, 2021, 15 (4): 980- 995. doi: 10.1109/JSTSP.2021.3073572
26	PAPURCU H, ROMSTADT J, HANSEN S, et al. A wideband four-channel SiGe D-band transceiver MMIC for TDM MIMO FMCW radar[C]//Proc. of the IEEE 23rd Topical Meeting on Silicon Monolithic Integrated Circuits in RF Systems, 2023: 12-15.
27	刘润虎. 毫米波MIMO雷达多维超分辨技术研究[D]. 哈尔滨: 哈尔滨工业大学, 2021.
	LIU R H. Research on multi-dimensional super resolution technology of millimeter wave MIMO radar[D]. Harbin: Harbin Institute of Technology, 2021.
28	陈辉. 空时信号处理等效原理与方法[M]. 北京: 清华大学出版社, 2021.
	CHEN H . Equivalent principle and method of space-time signal processing[M]. Beijing: Tsinghua University Press, 2021.
29	王永良. 空间谱估计理论与算法[M]. 北京: 清华大学出版社, 2004.
	WANG Y L . Spatial spectrum estimation theory and algorithms[M]. Beijing: Tsinghua University Press, 2004.
30	LIU W K, HE J, YU W X. A Computationally efficient scheme for FMCW radar detection and parameter estimation[C]//Proc. of the IEEE International Conference on Signal, Information and Data Processing, 2019.

算法名称	计算复杂度
ACM	O((MNL)²)
EVD	O((MNL)³)
SPS	O((MNL)m_sn_sl_s)
总体	O((MNL)²+(MNL)³+(MNL)m_sn_sl_s)

算法名称	计算复杂度
ACM	O((M_bN_bL_b)²)
EVD	O((M_bN_bL_b)³)
SPS	O((M_bN_bL_b)mnl)
总体	O((M_bN_bL_b)²+(M_bN_bL_b)³+(M_bN_bL_b)mnl)

参数	数值
中心频率/GHz	24
带宽/MHz	150
一个Chirp周期/μs	16
快拍数	200
Chirp个数	2×128
发射/接收阵元数	2/15
扩展虚拟阵元数	30
目标1的距离、角度、速度参数	(150 m, 5°, 3.0 m/s)
目标2的距离、角度、速度参数	(150.5 m, 8°, 4.0 m/s)

算法	CPU运行时间
二维MUSIC	128.621 735
本文所提算法	1.007 684
